WS8452DLS is a LoRa wireless data transmission module designed and manufactured by Chengdu Silent Smart Technology, which supports multiple frequency bands.
Developed with the first domestic LoRa-supporting LPWAN wireless communication protocol SoC chip from ASR.
Supports fixed-point transmission, transparent transmission, wireless wake-up, wireless relay function, and its high-performance MCU makes a substantial improvement in function and efficiency.
Internal data processing adopts 3-level cache, which greatly increases data stability and real-time performance.
Support ISM 868 / 915MHz frequency band.
Adopts LoRa spread spectrum technology, which has strong anti-interference performance and long communication distance.
Supports users to set their own communication key, and can not be read, greatly improving the confidentiality of user data.
Supports a maximum of 1W (about 30dBm) transmit power.
Support AT command configuration module
Supports Modbus programmable register read/write operation, which can be flexibly customized.
Supports Wake-on-Air, i.e. ultra-low power consumption, suitable for battery-powered applications
Support transparent transmission, fixed-point transmission, broadcast transmission, channel monitoring, wireless relay and other functions.
Support deep sleep, the power consumption of the whole machine in this mode is about 2uA.
Supports data transmission rate from 0.3k to 62.5kbps.
Industrial standard design, support -40 ~ +85 ℃ long time use
Antenna interface is optional, U.LF connector or postage stamp holes
